产品详情
- 400MHz to 2700MHz; < 1dB overshoot between 获得 transitions
- 13dB typical max 获得
- 23dB 获得 范围, 1dB 获得 步 resolution
- Excellent linearity +41dBm OIP3
- Noise figure 4dB
- ICC = 100mA
- 1.3mA standby current
- SPI interface
- Broadband, Internally Matched
The F0480 RF Variable 获得 Amplifiers (VGA) featuring Glitch-Free™ and Zero-Distortion™ technologies greatly reduces attenuation overshoot during attenuation 状态 changes and provides +41dBm OIP3 performance across a very wide bandwidth of 400MHz to 2700MHz at a typical current drain of 100mA. Furthermore, the device is internally matched so there is no need to optimize external matching elements.
- Multi-mode, Multi-carrier Receivers
- PCS1900 Base Stations
- DCS1800 Base Stations
- WiMAX and LTE Base Stations
- UMTS/WCDMA 3G Base Stations
- PHS/PAS Base Stations
- Point-to-Point 基础设施
- Public Safety 基础设施
- Broadband Repeaters
- GPS Receivers
- Distributed Antenna Systems
- Cable 基础设施
- Digital Radio
产品文档
类型
姓名
日期
动作
2025-08-25
AN-874 Using the TRL Calibration Board for the F0480 Matched Broadband RF VGA
Design & Development (Boards and Kit)
Evaluation System for F0480 Matched Broadband RF VGA
The F0480EVS is a fully populated evaluation board which allows the customer to easily evaluate the F0480 RF VGA. The attenuation setting may be set using the F0480’s serial control input. Header pins on the evaluation board allow setting the band 选择 and standby mode without off-board connections to the control inputs.
The F0480EVS is a complete hardware and software solution that allows customers to digitally control the F0480 with the USB output on a computer. The kit includes the F0480 evaluation board, as well as a USB Digital Control Board and interface cables. The software, guides , and instructional videos are available for download/查看ing on this page.
