RF and mmWave Mixers
The Axiro family of RF mixers featuring patented Zero-Distortion™ technology dramatically improves the maximum signal levels (IM3 tones) that a receiver can withstand at a desired Signal to Noise Ratio (SNR.) These devices are scalable, so alternately, one can run the devices in modes that reduce power consumption significantly while still maintaining high linearity.
CONTACT SALESProduct Selector
Part Number (17)
F0562
0
RF Frequency Min (GHz)
2.3
RF Frequency Max (GHz)
2.7
Supply Voltage (V)
5
Gain (dB)
29
OIP3 (dBm)
44
Description
-
LO Frequency (GHz)
-
IF Frequency (GHz)
-
IP1dB (dB)
-
Current (mA)
390
Package (mm)
10 x 10, 68–Pin QFN
F1100
Down-converting Mixer
RF Frequency Min (GHz)
0.698
RF Frequency Max (GHz)
0.915
Supply Voltage (V)
5
Gain (dB)
9
OIP3 (dBm)
41
Description
RF to IF Dual
LO Frequency (GHz)
0.848 – 1.365
IF Frequency (GHz)
0.15 – 0.45
IP1dB (dB)
13.1
Current (mA)
350
Package (mm)
6 x 6, 36–Pin QFN
F1102
Down-converting Mixer
RF Frequency Min (GHz)
0.4
RF Frequency Max (GHz)
1
Supply Voltage (V)
5
Gain (dB)
9.2
OIP3 (dBm)
43
Description
RF to IF Dual
LO Frequency (GHz)
0.5 – 1.15
IF Frequency (GHz)
0.05 – 0.3
IP1dB (dB)
12.5
Current (mA)
330
Package (mm)
6 x 6, 36–Pin QFN
F1130
Down-converting Mixer
RF Frequency Min (GHz)
0.4
RF Frequency Max (GHz)
1.1
Supply Voltage (V)
5
Gain (dB)
9.0
OIP3 (dBm)
43
Description
RF to IF Dual
LO Frequency (GHz)
0.5 – 1.13
IF Frequency (GHz)
0.03 – 0.40
IP1dB (dB)
9.0
Current (mA)
360
Package (mm)
7 x 7, 48–Pin QFN
F1763
Down-converting Mixer
RF Frequency Min (GHz)
2
RF Frequency Max (GHz)
2.9
Supply Voltage (V)
5
Gain (dB)
11.7
OIP3 (dBm)
42
Description
RF to IF Single
LO Frequency (GHz)
1.8 – 3
IF Frequency (GHz)
0.05 – 0.5
IP1dB (dB)
10.2
Current (mA)
200
Package (mm)
5 x 5, 20–Pin QFN
F1150
Down-converting Mixer
RF Frequency Min (GHz)
1.7
RF Frequency Max (GHz)
2.2
Supply Voltage (V)
5
Gain (dB)
8.5
OIP3 (dBm)
40
Description
RF to IF Dual
LO Frequency (GHz)
1.8 – 2. 65
IF Frequency (GHz)
0.05 – 0.45
IP1dB (dB)
13
Current (mA)
335
Package (mm)
6 x 6, 36–Pin QFN
F1152
Down-converting Mixer
RF Frequency Min (GHz)
1.4
RF Frequency Max (GHz)
2.2
Supply Voltage (V)
5
Gain (dB)
8.5
OIP3 (dBm)
43
Description
RF to IF Dual
LO Frequency (GHz)
1.35 – 2.1
IF Frequency (GHz)
0.05 – 0.35
IP1dB (dB)
13.2
Current (mA)
327
Package (mm)
6 x 6, 36–Pin QFN
F1162
Down-converting Mixer
RF Frequency Min (GHz)
2.3
RF Frequency Max (GHz)
2.7
Supply Voltage (V)
5
Gain (dB)
8.9
OIP3 (dBm)
43
Description
RF to IF Dual
LO Frequency (GHz)
1.8 – 2.9
IF Frequency (GHz)
0.05 – 0.5
IP1dB (dB)
13
Current (mA)
330
Package (mm)
6 x 6, 36–Pin QFN
F1178
Down-converting Mixer
RF Frequency Min (GHz)
3.4
RF Frequency Max (GHz)
3.8
Supply Voltage (V)
5
Gain (dB)
9
OIP3 (dBm)
37.5
Description
RF to IF Dual
LO Frequency (GHz)
2.9 – 3.62
IF Frequency (GHz)
0.05 – 0.5
IP1dB (dB)
11
Current (mA)
297
Package (mm)
6 x 6, 36–Pin QFN
F1180
Down-converting Mixer
RF Frequency Min (GHz)
1.4
RF Frequency Max (GHz)
2.7
Supply Voltage (V)
5
Gain (dB)
8.2
OIP3 (dBm)
38
Description
RF to IF Dual
LO Frequency (GHz)
1.35 – 2.90
IF Frequency (GHz)
0.03 – 0.55
IP1dB (dB)
9
Current (mA)
365
Package (mm)
7 x 7, 48–Pin QFN
F1192B
Down-converting Mixer
RF Frequency Min (GHz)
0.4
RF Frequency Max (GHz)
3.8
Supply Voltage (V)
3.3
Gain (dB)
11.1
OIP3 (dBm)
35
Description
Dual Wideband Gain - Settable
LO Frequency (GHz)
0.4 – 3.6
IF Frequency (GHz)
0.05 – 0.6
IP1dB (dB)
7
Current (mA)
240
Package (mm)
4 x 4, 24–Pin QFN
F1701
Down-converting Mixer
RF Frequency Min (GHz)
0.6
RF Frequency Max (GHz)
1.06
Supply Voltage (V)
5
Gain (dB)
11.8
OIP3 (dBm)
43
Description
RF to IF Single
LO Frequency (GHz)
0.63 – 1.26
IF Frequency (GHz)
0.07 – 0.3
IP1dB (dB)
10.2
Current (mA)
184
Package (mm)
5 x 5, 20–Pin QFN
F1751
Down-converting Mixer
RF Frequency Min (GHz)
1.4
RF Frequency Max (GHz)
2.5
Supply Voltage (V)
5
Gain (dB)
11.8
OIP3 (dBm)
43
Description
RF to IF Single
LO Frequency (GHz)
1.4 – 2.5
IF Frequency (GHz)
0.05 – 0.5
IP1dB (dB)
9.7
Current (mA)
190
Package (mm)
5 x 5, 20–Pin QFN
F1792
Down-converting Mixer
RF Frequency Min (GHz)
0.4
RF Frequency Max (GHz)
3.8
Supply Voltage (V)
3.3
Gain (dB)
11.1
OIP3 (dBm)
35
Description
Single Wideband Gain - Settable
LO Frequency (GHz)
0.4 – 3.6
IF Frequency (GHz)
0.05 – 0.6
IP1dB (dB)
7
Current (mA)
134
Package (mm)
4 x 4, 24–Pin QFN
F0502
0
RF Frequency Min (GHz)
0.6
RF Frequency Max (GHz)
1.0
Supply Voltage (V)
5
Gain (dB)
28.2
OIP3 (dBm)
44
Description
-
LO Frequency (GHz)
-
IF Frequency (GHz)
-
IP1dB (dB)
-
Current (mA)
480
Package (mm)
10 x 10, 68–Pin QFN
F0552
0
RF Frequency Min (GHz)
1.7
RF Frequency Max (GHz)
2.0
Supply Voltage (V)
5
Gain (dB)
28
OIP3 (dBm)
46
Description
-
LO Frequency (GHz)
-
IF Frequency (GHz)
-
IP1dB (dB)
-
Current (mA)
445
Package (mm)
10 x 10, 68–Pin QFN
F159V
Integrated TRx IC - 450MHz to 2800MHz
RF Frequency Min (GHz)
0.45
RF Frequency Max (GHz)
2.8
Supply Voltage (V)
3.3
Gain (dB)
18.3
OIP3 (dBm)
31
Description
-
LO Frequency (GHz)
-
IF Frequency (GHz)
-
IP1dB (dB)
-
Current (mA)
685
Package (mm)
10 x 10, 68–Pin QFN
